MIN 2500-6000TL-XH

Growatt New Energy MIN 2500-6000TL-XH

Inversolar S.L.
Tipo: Conectado a la Red
Gama de Potencia: --
Región: España España
Contacte al Vendedor
Nota: Su Consulta se enviará directamente a Inversolar S.L..

Producto Alternativo

COPIA-SH

Jiangsu Weiheng Intelligent Technology
Desde €0,129 / Wp
  • Tipo: Hibrida
  • Garantía de Producto: --
  • Clase Protectora: IP65
  • Dimensiones: 425x500x170 mm
  • Peso: 19,8 kg

Características del Producto

No. de Modelo
MIN 3000TL-XH MIN 4200TL-XH MIN 5000TL-XH MIN 6000TL-XH
Garantía
Garantía de Producto (Min)
5 Años 5 Años 5 Años 5 Años
Datos de entrada DC
Potencia Maxima DC
6 kW 8,4 kW 10 kW 10 kW
Tension maxima
500 V 550 V 550 V 550 V
Tension Nominal de red DC
360 V 360 V 360 V 360 V
Tension minima para iniciar alimentacion
100 V 100 V 100 V 100 V
Maxima corriente DC
27 A 27 A 27 A 27 A
Rango de Tension MPP(T)
70~500 V 70~550 V 70~550 V 70~550 V
Tension de MPPT
2 2 2 2
Entrada DC
2 2 2 2
Conectores
MC4 MC4 MC4 MC4
Datos de salida AC
Potencia nominal AC
3 kW 4,2 kW 5 kW 6 kW
Rango de Tension AC para Salida
180~280 V 180~280 V 180~280 V 180~280 V
Tension nominal de red AC
230 V 230 V 230 V 230 V
Maxima corriente AC
13,6 A 19 A 22,7 A 27,2 A
Rango de frecuencia
45-65 Hz 45-65 Hz 45-65 Hz 45-65 Hz
Frecuencia
50, 60 Hz 50, 60 Hz 50, 60 Hz 50, 60 Hz
Distorsion (THD)
3 % < 3 % < 3 % < 3 %
Numero de fases de inyeccion
1 1 1 1
Eficiencia maxima
98,2 % 98,4 % 98,4 % 98,4 %
Euro-eficiencia
97,1 % 97,2 % 97,5 % 97,5 %
Datos generales
Dimensiones (A/A/F)
350x375x160 mm 350x375x160 mm 350x375x160 mm 350x375x160 mm
Peso
10,8 kg 10,8 kg 10,8 kg 10,8 kg
Consumo nocturno
< 10 W < 10 W < 10 W < 10 W
Temperatura de Funcionamiento -14 ~ +50 ℃
Transformador Sin Transformador
Clase Protectora IP65
Humedad 0-100 %
Enfriamiento Natural
Altitud maxima 4000 m
Interface RS 485, USB, WLAN
Visualizacion LED
Caracteristicas de Proteccion
Caracteristicas de Proteccion Proteccion Anti Aislante (ENS), Proteccion Corto-Circuito, Dispositivo de Corriente Residual (RCD), Proteccion contra Inversiones de la Polaridad, Proteccion contra Sobretension y Sobrecarga, Monitorizacion de fallo de Toma de Tierra, Monitorizacion de Red
PDF
Descargar pdf del Fabricante

Inversolar S.L.

Click to show company phone
https://inversolar.es
España
Pol. Ind El Nevero, Calle. Río Segura, Nave 4, 06006 Badajoz
Nota: Su Consulta se enviará directamente a Inversolar S.L..
Descripción de la Empresa

Inversolar is a company that was founded in 2006 with the aim of promoting the presence of renewable energies at a national level. Without leaving behind other branches of clean energy, Inversolar has focused its efforts on the photovoltaic sector; specifically, on off-grid systems, solar pumping and self-consumption systems or grid-connected systems. At present we have a trained and specialized staff to provide a quality service in accordance with the requirements of our customers.
